Technical Specifications of the Wooden Pole
-
Diameter at 30 cm from the top: 15–18 cm
-
Diameter at 10 cm from the base: 21–24 cm
-
Permissible length deviation: 0 cm to +10 cm
-
Permissible diameter deviation: -0.4 cm to +0.5 cm
-
Corrosion rate (max.): < 2 g/m²/day
-
Static bending strength: 62 MPa
-
Preservative uptake: 12 kg/m³
-
Average preservative penetration depth: 1 cm
-
Preservative used: Wolmanit CX-10
Thanks to the impregnation treatment, the poles are resistant to weather conditions.
The poles are suitable for use in:
-
Telecommunication networks
-
Subscriber line installation
-
Fault repair
-
Guy post installation
-
CCTV systems
-
Stadium lighting
Each pole is supplied with a certificate of conformity.
Telecommunication wooden poles are used primarily for the construction and maintenance of telecommunication networks and temporary utility poles. Their main advantages are light weight, low cost, natural material, and long service life. They are typically pressure-treated with salt-based preservatives to resist weather, insect, and fungal damage. Poles are produced in various lengths and diameters depending on the network requirements.
The poles are not pre-drilled. Upon request, our team can assist with cutting and drilling:
-
Cut to length: HUF 3,000 + VAT
-
Drilling: HUF 3,000 + VAT
We also offer transport and crane unloading for wooden poles and stays – request your quote today!
