24 szálas (2x12) Sterlite kültéri optikai kábel, mikro behúzó/lég, G652D N
Eredeti nettó egységár: 217 Ft
1m / egyesével
Price: 217 Ft
24 szálas (2x12) Sterlite kültéri optikai kábel, mikro behúzó/lég, G652D N
Fibre
Single Mode Optical Fibre Sterlite Fibre, ITU.T - G.652D
Maximum Cabled Fibre Attenuation dB/Km 1310nm : 0.36, 1550nm : 0.23
PMDq ≤ 0.2 ps/√km

Micro Module
Fibre/Module 12 Nos. Fiber wiped with thixotropic gel
Module Soft thermoplastic material

Cable
Water Blocking Elements Water Swellable Yarns to prevent Water ingress in Cable
Peripheral Strength Member High Tensile Aramid Yarn to meet required Tensile Strength
Water Blocking Tape To Cover the Core and Water Protection (if required)
Embedded Strength Member 4 Nos. Fibre Reinforced Plastic(FRP) Embedded in Sheath to give Strength & Antibuckling
Ripcord Polyester based twisted yarns for Easy Stripping of Sheath
Outer Sheath UV Proof Black High Density Polyethylene >1.0 mm Thickness
Fibre
Single Mode Optical Fibre Sterlite Fibre, ITU.T - G.652D
Maximum Cabled Fibre Attenuation dB/Km 1310nm : 0.36, 1550nm : 0.23
PMDq ≤ 0.2 ps/√km

Micro Module
Fibre/Module 12 Nos. Fiber wiped with thixotropic gel
Module Soft thermoplastic material

Cable
Water Blocking Elements Water Swellable Yarns to prevent Water ingress in Cable
Peripheral Strength Member High Tensile Aramid Yarn to meet required Tensile Strength
Water Blocking Tape To Cover the Core and Water Protection (if required)
Embedded Strength Member 4 Nos. Fibre Reinforced Plastic(FRP) Embedded in Sheath to give Strength & Antibuckling
Ripcord Polyester based twisted yarns for Easy Stripping of Sheath
Outer Sheath UV Proof Black High Density Polyethylene >1.0 mm Thickness
